$23.80
Original: $79.34
-70%BOYA BY-XM6-S1 MINI Ultracompact 2.4GHz Dual-Channel Wireless Microphone System—
$79.34
$23.80The Story
BY-XM6-S1 Mini
Ultracompact 2.4GHz Dual-Channel Wireless Microphone System- Ultra-compact design
- Global free frequency 2.4GHz ISM wireless technology
- Broadcast-quality sound
- Optional stereo and mono modes
- Wide compatibility
- OLED screen on receiver
- Real time monitoring available
- Flexible gain setting
BY-XM6 Mini is an advanced and versatile 2.4GHz wireless microphone system that expands on the success of the classic BY-XM6 microphone series with a further improvement in portability. With the features of ultra-compact, stable signal transmission, it ensures that the crystal-clear sound can be captured and delivered. Furthermore, the transmitters can automatically pair with the receiver when turned on, and thanks to the ultra-compact design, they can be easily clipped to clothing without creating any sensation, providing users with a high-quality recording experience, especially during outdoor activities
Mini yet Mighty
In terms of the BY-XM6 Mini's design concept, it maintains the priority of being lightweight and comfortable, the transmitter each weighs only 14.5g and 34g for the receiver accordingly, which is very impressive progress and what's called a “compact, yet versatile” wireless microphone. Plus, the receiver features an OLED display to show all vital information, making sure every detail during the shooting can be under control.
Global Free Frequency 2.4GHz ISM Wireless Technology
By introducing an advanced 2.4GHz ISM wireless transmission technology, a built-in omnidirectional microphone, and an automatic frequency-hopping function, the BY-XM6 Mini microphone system delivers professional high-quality sound with an impressive sensitivity of -39dB and effectively avoids static noise and auto dropouts. Moreover, it ensures stable and interference-free signal transmission with a range of up to 100m without obstacles.
High-performance Battery & Wide Compatibility
The BY-XM6 Mini is designed to perfectly work with DSLR, mirrorless, mixers, modern computers, smartphones, tablets, and more. In addition, both transmitter and receiver are equipped with a built-in rechargeable lithium-ion battery that makes it a worthwhile option for content creators to consider if they are constantly shooting outdoors.
BY-XM6 TX Mini Transmitter
| Transmission Type | 2.4GHz lSM Frequency |
| Modulation | GFSK |
| Operating Range | Up to 328ft (100m) (without obstacle) |
| RF Output Power | <10mw |
| Polar Pattern | Omnidirectional |
| Frequency Response | 35Hz-18KHz |
| Maximum SPL | 120dB SPL |
| Sensitivity | -39dB |
| SNR | >77 dB |
| Power Requirements | Built-in Li-ion Battery or USB-C DC 5v or Charging Contact |
| Built-in Battery Life | Approx.4.5 hours |
| Antenna | PIFA Antenna |
| Audio lnputs | Built-in Microphone |
| Weight | Approx.14.5g(0.5oz) |
| Dimensions | 46x23.92x15mm |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -20°C to +55℃ |
BY-XM6 RX Receiver
| Transmission Type | 2.4GHz Digital Frequency |
| Modulation | GFSK |
| Operating Range | Up to 328ft (100m)(without obstacle) |
| Audio Output Connector | 3.5mm Headphone Jack 3.5mm TRS Output Jack |
| Audio Output Level | -60 dBV to -20dBV |
| Power Requirements | Built-in Li-ion Battery or USB-C DC 5v or Charging Contact |
| Built-in Battery Life | Approx.7 hours |
| Antenna | PIFA Antenna |
| Weight | Approx.32g(1.13oz) |
| Dimensions | 62.1×31.6×16.5mm |
| Operating Temperature | -10℃ to 50°C |
| Storage Temperature | -20℃ to +55°C |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
BY-XM6-S1 Mini
Ultracompact 2.4GHz Dual-Channel Wireless Microphone System- Ultra-compact design
- Global free frequency 2.4GHz ISM wireless technology
- Broadcast-quality sound
- Optional stereo and mono modes
- Wide compatibility
- OLED screen on receiver
- Real time monitoring available
- Flexible gain setting
BY-XM6 Mini is an advanced and versatile 2.4GHz wireless microphone system that expands on the success of the classic BY-XM6 microphone series with a further improvement in portability. With the features of ultra-compact, stable signal transmission, it ensures that the crystal-clear sound can be captured and delivered. Furthermore, the transmitters can automatically pair with the receiver when turned on, and thanks to the ultra-compact design, they can be easily clipped to clothing without creating any sensation, providing users with a high-quality recording experience, especially during outdoor activities
Mini yet Mighty
In terms of the BY-XM6 Mini's design concept, it maintains the priority of being lightweight and comfortable, the transmitter each weighs only 14.5g and 34g for the receiver accordingly, which is very impressive progress and what's called a “compact, yet versatile” wireless microphone. Plus, the receiver features an OLED display to show all vital information, making sure every detail during the shooting can be under control.
Global Free Frequency 2.4GHz ISM Wireless Technology
By introducing an advanced 2.4GHz ISM wireless transmission technology, a built-in omnidirectional microphone, and an automatic frequency-hopping function, the BY-XM6 Mini microphone system delivers professional high-quality sound with an impressive sensitivity of -39dB and effectively avoids static noise and auto dropouts. Moreover, it ensures stable and interference-free signal transmission with a range of up to 100m without obstacles.
High-performance Battery & Wide Compatibility
The BY-XM6 Mini is designed to perfectly work with DSLR, mirrorless, mixers, modern computers, smartphones, tablets, and more. In addition, both transmitter and receiver are equipped with a built-in rechargeable lithium-ion battery that makes it a worthwhile option for content creators to consider if they are constantly shooting outdoors.
BY-XM6 TX Mini Transmitter
| Transmission Type | 2.4GHz lSM Frequency |
| Modulation | GFSK |
| Operating Range | Up to 328ft (100m) (without obstacle) |
| RF Output Power | <10mw |
| Polar Pattern | Omnidirectional |
| Frequency Response | 35Hz-18KHz |
| Maximum SPL | 120dB SPL |
| Sensitivity | -39dB |
| SNR | >77 dB |
| Power Requirements | Built-in Li-ion Battery or USB-C DC 5v or Charging Contact |
| Built-in Battery Life | Approx.4.5 hours |
| Antenna | PIFA Antenna |
| Audio lnputs | Built-in Microphone |
| Weight | Approx.14.5g(0.5oz) |
| Dimensions | 46x23.92x15mm |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -20°C to +55℃ |
BY-XM6 RX Receiver
| Transmission Type | 2.4GHz Digital Frequency |
| Modulation | GFSK |
| Operating Range | Up to 328ft (100m)(without obstacle) |
| Audio Output Connector | 3.5mm Headphone Jack 3.5mm TRS Output Jack |
| Audio Output Level | -60 dBV to -20dBV |
| Power Requirements | Built-in Li-ion Battery or USB-C DC 5v or Charging Contact |
| Built-in Battery Life | Approx.7 hours |
| Antenna | PIFA Antenna |
| Weight | Approx.32g(1.13oz) |
| Dimensions | 62.1×31.6×16.5mm |
| Operating Temperature | -10℃ to 50°C |
| Storage Temperature | -20℃ to +55°C |
